Small Form Factor QSFP+ Active Optical Cable / Pluggable 40g Aoc Cable

  • Small Form Factor QSFP+ Active Optical Cable / Pluggable 40g Aoc Cable
  • Small Form Factor QSFP+ Active Optical Cable / Pluggable 40g Aoc Cable
  • Small Form Factor QSFP+ Active Optical Cable / Pluggable 40g Aoc Cable
  • Small Form Factor QSFP+ Active Optical Cable / Pluggable 40g Aoc Cable
Place of Origin China
Brand Name Hangalaxy
Certification ROHS, UL, SGS, CE
Model Number HGYN-0986
Minimum Order Quantity MOQ Saying is 10pcs
Price Negotiation By email or Phone Call
Packaging Details 1PCS Each Individual Quality PE Bag
Delivery Time 7 Business Days
Payment Terms L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability 25055PCS Monthly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Cable Color Aqua Connector Type QSFP+ To QSFP+
Data Rate 40Gbps Minimum Bend Radius 7.5mm
Cable Length 50m Jacket Material OFNP
Protocols 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel Fiber Mode Multimode, OM3
High Light

40g aoc cable

,

fan out cable
Leave a Message
Product Description

Quad Small Form-factor Pluggable 40G QSFP+ Active Optical Breakout Cable



This AOC is a high performance cable for short-range multi-lane data communication and interconnect applications. It integrates four data lanes in each direction with 40Gbps aggregate bandwidth. Each lane can operate at 10.3125 Gbps. These cables also support 4 x 10G Infini-Band QDR applications and are backwards compatible to the 4 × 5G IB DDR and 4 × 2.5G IB single IB SDR applications.



Keyed Characteristics


● Quad Small Form-factor Pluggable Plus (QSFP+) to 4 x Small Form-factor Pluggable Plus (SFP+) active optical cable.
● Active fibre cable assembly.
● 41.2 Gbit/sec to 4 x 10.5 Gbit/sec
● Operating distance of 10 metre.
● Operating temperature 0 - 70 c.
● Transmission media Multi-mode Fibre.



Safety Standards


● EN 60825-1 (2007)/EN 60825-2 (2010);
● FDA 21CFR1040.10 Class 1 Laser Product;
● Compliance with Restriction on Hazardous Substances (RoHS) directive;
● CE Marked.



Applications


● 40GbE and 10GbE break-out applications for Datacom switch and router connections;
● 40G to 4×10G density applications for Datacom and Proprietary protocol applications;
● Datacenter.



Absolute Maximum Ratings



Parameter Symbol Min Max Unit
Storage Temperature TST -20 85 ℃
Relative Humidity RH 0 85 ％
Case Operating Temperature TOPC 0 70 ℃
Supply Voltage VCC -0.3 3.6 V



Recommended Operating Conditions



Parameter Symbol Min Typical Max Unit
Operating Case temperature TA 0   +70 ℃
Supply Voltage VCC 3.13 3.3 3.47 V
Supply current Icc     300 mA
Channel Data Rate Dr - 25.78125   Gbps



Transmitter



Parameter Symbol Min Typical Max Unit
Input differential impedance Zin 90 100 110 Ω
Differential Data Input Swing Vin PP 300   1100 mV
Transmit Enable Voltage VEN     0.8 V
Transmit Disable Voltage VD 2.0     V
Average launch power PAVG -7.5 -1 +2.5 dBm
Extinction Ratio ER 2.0     dB
Centre Wavelength λc 840 850 860 nm



Small Form Factor QSFP+ Active Optical Cable / Pluggable 40g Aoc Cable 0



CWDM/DWDM Module Facilicy



Small Form Factor QSFP+ Active Optical Cable / Pluggable 40g Aoc Cable 1



Hangalxy AWG Module Factory



Small Form Factor QSFP+ Active Optical Cable / Pluggable 40g Aoc Cable 2



The rate of Hangalaxy 40G AOC cable is quite stable on our Cisco Nexus 9000 series equipment with no compatibility issue. Very pleased with my first order for nice products' performance. Regarding to my next project, will order FS products again.



Dispatch



All orders received before 4pm Monday to Friday will ship the same day. We will endeavour to ship any orders received after this deadline, however please call if you require confirmation.
