HDMI 2.1 4K 8K HDMI Active Optical Cable / 8K Hdmi 2.1 48gbps Cable 60Hz 4 4 4

Basic Information
Place of Origin: China
Brand Name: Hangalaxy
Certification: CE, SGS, RoHs, UL
Model Number: HGYN-0256
Minimum Order Quantity: MOQ Saying is 10pcs
Price: Negotiation By email or Phone Call
Packaging Details: 1PCS Each Individual Quality PE Bag
Delivery Time: 7 Business Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 5055PCS Monthly
Cable OD: 3.0mm Cable Material: TPU
Cable Color: Yellow Connector: HDMI 2.1
Data Rate: 48Gbps Length: 150m
High Light:

hdmi 2.0 active optical cable

,

hdmi high speed cable 4k

150m 8K@60Hz 4:4:4 48Gbps HDMI 2.1 Active Optical Cable Pure Fiber



(1) 2.0 32Gbps HDMI AOC, Chip Power Consumption≤750mW;
(2) Support 4096*2160 4k@60hz, digital encoding format: 4: 4: 4 sampling, support 12-bit color, 3D, HDCP 2.2 and 1.4 HDR, Ethernet and ARC functions are not supported;
(3) The technology solution we using Micro lens array optical system;
(4) Using optical transparent transmission technology, using 6 cores OM3 pure optical cable, no need to install additional drivers, excellent compatibility;
(5) External power supply is required. A 25cm USB interface cable is provided at each end of the Display / Source. The external power supply jack is used for backup power supply at the Source end, and a 5V power supply interface must be inserted at the Display end;
(6) The optoelectronic module is packaged with a metal fully shielded inner shell, it strongly against to electromagnetic radio frequency signal interference and has a transmission distance up to 300 meters;
(7) Using the transparent transmission technology for no driver program and well compatible for. Its easy Plug and Play;
(8) Our HDMI connector made of PVC by injection molding, marked it as TX / RX, Source / Display and ▶◀, so the cable has fixed directivity and no error installation;
(9) Using bend-resistant glass fiber could bending without broken, TPU for outer jacket;
(10) Integrated HDMI optical fiber cable can be cut and connected with customized optical cable.



Technical Parameter



Cable Length Max 150 meters
Connector Type HDMI Standard Type A (Male) - HDMI Standard Type A (Male); USD dual Male
Connector Dimension L5.07cm x W1.9cm x Thickness 9.1mm
Data Speed 48Gbps HDMI 2.1, support 8K@60HZ, Ultra HD image transmission, 12-bit color

Power Supply

External power supply is required. A 25cm USB interface cable is provided at each end of the Display / Source. The external power supply jack is used for backup power supply at the Source end, and a 5V power supply interface must be inserted at the Display end.
Power Consumption ≦750mW



Physical / Environment
Cable Diameter 3.0mm
Tensile (Long-term / Short-term) 130N/230N
Bending (Long-term / Short-term) 200N/400N
Minimum Winding Radius 18mm
Operating / Storage Temp. 0℃ ~ 50℃ / -20℃ ~ 70℃



Products Model and Spec



Product Name Model AOC Length

Hangalaxy HDMI AOC Transmission System

(2.0 32Gbps F Series)

HD/2.1-15F 15mtrs
HD/2.1-20F 20mtrs
HD/2.1-25F 25mtrs
HD/2.1-30F 30mtrs
HD/2.1-35F 35mtrs
HD/2.1-40F 40mtrs
HD/2.1-45F 45mtrs
HD/2.1-50F 50mtrs
HD/2.1-60F 60mtrs
HD/2.1-70F 70mtrs
HD/2.1-80F 80mtrs
HD/2.1-90F 90mtrs
HD/2.1-100F 100mtrs
HD/2.1-110F 110mtrs
HD/2.1-120F 120mtrs
HD/2.1-130F 130mtrs
HD/2.1-250F 250mtrs
HD/2.1-300F 300mtrs
