2.0mm 10G LC to LC Pigtail Fiber Cable / Multimode OM3 Patch Cord Pigtail

Place of Origin China
Brand Name Hangalaxy
Certification CE, SGS, UL, ROHS
Model Number HGYN-0160
Minimum Order Quantity MOQ Saying is 10pcs
Price Negotiation By email or Phone Call
Packaging Details 1PCS Each Individual Quality PE Bag
Delivery Time 7-10 Business Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 25000PCS Monthly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Connector 1 LC Connector 2 LC
Polish Type UPC Cable OD 2.0mm
Cable Color Aqua Cable Jacket LSZH
Fiber Mode Multimode Wavelength 850nm
High Light

fiber optic pigtail splicing

,

patch cord pigtail

Leave a Message
Product Description

2.0mm 10G LC to LC Fiber Multimode OM3 Optic Pigtails Simplex Patch Cable



Description



The single-mode and multimode fiber optic pigtails shall be available in 3-meter lengths, made of OFNR fiber optic cable, and be compliant with TIA-568-C.3. Single-mode pigtails shall come in ST, SC, and LC connector styles, and offer UPC and APC polish types. Insertion loss shall average .3dB, but not exceed .5dB at 1310 nm and 1550nm per mated pair. Multimode pigtails shall come in ST, SC, and LC connector styles, and offer 50 μm (10G, 300 m) lazer optimized, and 62.5 μm core styles. Insertion loss shall average .3dB, but not exceed 0.5dB at 1300 nm per mated pair. Hangalaxy’s single-mode, standard multimode, and laser optimized multimode fiber optic pigtails are designed to support mechanical and fusion splicing for fiber cabling systems.



Features



(1) Standard length of three meters. Custom lengths available upon request;
(2) All connectors have precision pre-radiused zirconia ferrules;
(3) Corning glass fiber or equivalent;
(4) Other connectors available upon request (MU, FC, MT-RJ);
(5) 0.9 mm tight buffered OFNR cable (white) in 62.5/125 μm, 50/125 μm, 50/125.



Applications



1. Active device termination;
2. CATV system;
3. Active device terminations;
4. LAN / WAN;
5. FTTx (including FTTB, FTTC, FTTD, FTTH).



Technical Parameter



Fiber Type SM MM



Connector Tytpe

MTRJ

D4, FC, SC, ST, LC,

E-2000, MU

D4, FC, SC, ST, LC,

E-2000, MU

MTRJ
Insertion Loss (Typical) ≤0.4dB ≤0.2dB ≤0.4dB ≤0.2dB
Insertion Loss (Max) ≤0.5dB ≤0. 3dB ≤0.3dB ≤0.5dB



Return Loss (Typical)

PC   ≥50dB
APC ≥65dB
UPC ≥55dB ≥55dB
Mating Durability ≤0.2dB
Durability ≥1000 times
Storage Temperature - 40℃~+ 85



Cable Diameter 0.9mm
Jacket Color Yellow or Customized
Connector LC
Polishing Type APC
Fiber Type G657A1, SM, Single-mode
Cable Length 1m / 10ft; or customized



Environmental Space Plenum
Operating Temperature -10 °C to +60 °C (+14 °F to +140 °F)



2.0mm 10G LC to LC Pigtail Fiber Cable / Multimode OM3 Patch Cord Pigtail 0



PLC Spliters Workshop



2.0mm 10G LC to LC Pigtail Fiber Cable / Multimode OM3 Patch Cord Pigtail 1



2.0mm 10G LC to LC Pigtail Fiber Cable / Multimode OM3 Patch Cord Pigtail 2



Quality Guarantee



Hangalaxy has those fiber optical patch cables in stock and ready to ship. This cable is tested for 100% functionality and guaranteed compatible for outstanding network performance. Now you have a reliable, compatible and affordable means to expand your network while maintaining its integrity. We can provide this cable in any lengths. If the length you need is not listed on our website, please feel free to contact us.
