3.0mm G.657A1 Pre Terminated Optic Cable SC APC To LC UPC

  • 3.0mm G.657A1 Pre Terminated Optic Cable SC APC To LC UPC
Place of Origin China
Brand Name Hangalaxy
Certification CE, FDA, SGS, RoHs, ISO9001:2008
Model Number 985
Minimum Order Quantity MOQ Saying is 10pcs
Price Negotiation By email or Phone Call
Packaging Details 1PCS Each Individual Quality PE Bag
Delivery Time 7-10 Business Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 25000PCS Monthly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Connector 1 LC UPC Connector 2 SC APC
Fiber Mode G.657A1 Singemode Fiber Count 48
Polish Type APC, UPC Cable OD 3.0mm
Cable Color Yellow Cable Length 10m
High Light

G.657A1 Pre Terminated Optic Cable

,

3.0mm Pre Terminated Optic Cable

,

SC APC To LC UPC Cable
Leave a Message
Product Description

48 Cores SC APC to LC UPC SM G.657A1 Singemode Pre Terminated Fiber Optic Cable


Feature & Keyed Characteristic


● Strong, flexible and easy to install;
● Ideal for indoor applications, thanks to the LSZH sheath;
● Great mechanic resistance;
● Totally dielectric.



Item Description


The Hangalaxy Multifiber cable made by 900μm diameter optical patch cords helically wrapped on a central element. It is possible to order the cable with all available connectors.



Technical Parameter



CABLE YELLOW FANOUT SINGLE-MODE
Applicable standards

CEI/EN 60793

CEI/EN 60794-1
CONSTRUCTION PERFORMANCE
Pulling load resistance (N) 4-6 fo: 600 / 800 8 – 12 – 16 fo: 1.000 / 1.500 / 2000 18 - 48 fo: 2.000 / 2.500
Crush resistance (N/cm) Da 200 a 250
Static bending radius (mm) 10 times x outer diameter
Dynamic bending radius (mm) 20 times x outer diameter
Temperature (°C) -20 / +80
Installing temperature (°C) -10 / +60
Temperature (°C) -20 / +80
MATERIALS
Outer sheath LSZH (yellow RAL 1018)
External sheath of single fiber LSZH (yellow RAL 1018)
Secondary sheath of single fiber Nylon - SEMITIGHT
Strenght member Aramid yarns
FIBER
SM - 9/125 SMF-28e
CONSTRUCTION FEATURES
Number of fibers 12 24 48
Outer diameter (mm) 10.5mm 13.5mm 17.8
Weight (kg/km) 50 78 135
Single fiber external diameter (mm) 0.9 ±0,1
Connectors Standard of LC, ST, FC, SC etc.



3.0mm G.657A1 Pre Terminated Optic Cable SC APC To LC UPC 0



Application in the field



3.0mm G.657A1 Pre Terminated Optic Cable SC APC To LC UPC 1



Fiber Optic Patch Cord, Multi-fiber, Singlemode, 4 fibers, SC/UPC to SC/UPC, yellow, 16 m
