FTTH 24 Strands G657a1 Singlemode Pre Terminated Cable LC UPC

Basic Information
Place of Origin: China
Brand Name: Hangalaxy
Certification: CE, UL, ROHS, SGS
Model Number: 009
Minimum Order Quantity: MOQ Saying is 10pcs
Price: Negotiation By email or Phone Call
Packaging Details: 1PCS Each Individual Quality PE Bag
Delivery Time: 7 Business Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 25055PCS Monthly
Cable Material: LSZH Fiber Mode: SM Singlemode G657a1
Connector: LC UPC Color: Yellow
Insertion Loss: 0.35dB Return Loss: 50dB
Application: FTTH FTTB FTTX Network, Telecommunication, Optic Fiber Splicing, Rack Mounted Indoor Material: Rugged Plastic Layer
Weight: 12g
High Light:

G657a1 Singlemode Pre Terminated Cable


FTTH Singlemode Pre Terminated Cable


LC UPC Pre Terminated Cable

24 Strands LC UPC SM Singlemode G657a1 Pre Terminated Fiber Optic LSZH Cable



The Hangalaxy Multi-fiber cable assemblies offer premium performance, reliability and scalability to optical networks and systems, and provide interconnect capability between equipment and fiber distribution units and equipment to equipment. They are designed, manufactured and tested in compliance with Telcordia, ANSI/TIA, and IEC industry standards. The quality of the components, and workmanship used to build Wirewerks multi-fiber cable assemblies ensures flawless connections. Wirewerks understands the need for application specific multifiber cable assemblies and accordingly, our factory has the capability and the experience to custom build to meet the most stringent mechanical and optical performance specifications. All Wirewerks multi-fiber cable assemblies are provided with an identification label and have a unique serial number assigned to them. The information appearing on these labels consist of the part number, product description, serial number, and actual test results for each connector for easy product recognition and traceability.


Keyed Characteristic

√ 100% insertion loss, return loss, end face geometry tested, and visual inspection for contaminants.
√ All multi-fiber cable assemblies come with actual test results for each connector.
√ Interferometer test results available upon request.
√ Zero error performance.
√ Single mode OS2, and multimode OM1, OM2, OM3, OM4.
√ Bend insensitive fiber available.
√ Standard connectors MPO, LC, SC, ST, FC, MTRJ, Single mode connectors’ default polish is UPC (≤-55 dB return loss).
√ Quick and easy on-site deployment.
√ Full range of cable constructions and ratings.
√ Factory installed pulling eye available.


Technical Parameter


Applicable standards

CEI/EN 60793

CEI/EN 60794-1

Pulling load resistance (N) 4-6 fo: 600 / 800 8 – 12 – 16 fo: 1.000 / 1.500 / 2000 18 - 48 fo: 2.000 / 2.500
Crush resistance (N/cm) Da 200 a 250
Static bending radius (mm) 10 times x outer diameter
Dynamic bending radius (mm) 20 times x outer diameter
Temperature (°C) -20 / +80
Installing temperature (°C) -10 / +60
Temperature (°C) -20 / +80
Outer sheath LSZH (yellow RAL 1018)
External sheath of single fiber LSZH (yellow RAL 1018)
Secondary sheath of single fiber Nylon - SEMITIGHT
Strenght member Aramid yarns
SM - 9/125 SMF-28e
Number of fibers 12 24 48
Outer diameter (mm) 3.0mm 4.5mm 10.5
Weight (kg/km) 20 34 56
Single fiber external diameter (mm) 0.9 ±0,1
Connectors Standard of LC, ST, FC, SC etc.


FTTH 24 Strands G657a1 Singlemode Pre Terminated Cable LC UPC 0


FTTH 24 Strands G657a1 Singlemode Pre Terminated Cable LC UPC 1


Could you please let us know your currently AV project might using our cable solution? Our premium HDMI, DP, USB, DVI cable using fiber technology for long distance signal transmitted. Our HDMI AOC has below advantages:


1, Compatibility, Stability and Consistency.
2, High bandwidth and long-distance max 300mtrs signal transmission.
3, Easy installation, plug and play.
4, Slim, flexible and bendable to any angle.
5, Flexible and external impact resistance optical glass fiber cable.
6. Errorless transmitted and 0% loss against external interference.
7, Using telecom grade laser meet 30,000 hours life.


Feel any questions please do not hesitate contact us.
