Single Mode Fiber Optic FBG Reflector / Fiber Optic Reflector Fiber Bragg Grating

Basic Information
Place of Origin: China
Brand Name: Hangalaxy
Certification: ISO9001, CE, RohS, SGS, UL
Model Number: HGYN-00012
Minimum Order Quantity: MOQ Saying is 10pcs
Price: Negotiation By email or Phone Call
Packaging Details: 1PCS Each Individual Quality PE Bag
Delivery Time: 7-10 Business Days
Payment Terms: L/C, D/A, D/P, Western Union, MoneyGram
Supply Ability: 25000PCS Monthly
Connector: LC Polish Type: APC
Wavelength: 1625nm Color: Green
Material: ABS Plastic Pass Band: 1.0dB
PDL: 0.4dB Max Power Optical Handling: 27dBm
High Light:

fiber bragg grating reflector

,

optical reflector

Fiber Bragg Grating 1650nm OTDR FBG LC APC Singlemode Fiber Optic Reflector



Fiber reflector, also known as fiber Bragg grating filter, is usually installed in the front end of ONU of optical network. Combined with OTDR equipment, it can realize the point-to-point (PTP) or point-to-multipoint (PTMP) network monitoring of optical link, which can reflect the network abnormality quickly and accurately; The LC pigtail fiber (FBG) reflector provided by Hangalaxy has the advantages of low insertion loss, high reflectivity, convenient installation, etc., and is an ideal optical device for network link monitoring; It is widely used in PON network,OTDR testing, central computer room testing, FTTX and other fields.



Characteristics



(1) High-precision ceramic ferrules are used to achieve high-precision alignment of connectors to ensure long-term stable mechanical and optical performance.
(2) The fiber (FBG) reflector provided by Hanalaxy meets the working environment of -20~70 °C, with an average of more than 500~1000 insertion and removal tests, with stable performance and reliable quality.
(3) Low insertion loss.
(4) Easy connection for adapter structure.
(5) Compliant with Telcordia GR-326-CORE, Telcordia GR-1221-CORE.
(6) Example: Fiber (FBG) reflector is installed in the front end of optical network ONU, and the network diagnosis of FTTX is realized with OTDR equipment.



Specification



Item Parameter Specification Unit Remarks
1 Wavelength Range Pass Band 1260~1625 nm -
    Reflect Band 1644.5~1655.5 nm





2





Pass Band



IL

≤1.0 dB @1260~1360
≤1.0 dB @1460~1600
≤1.5 dB @1600~1625



ORL

>35 dB @1260~1580
>30 dB @1580~1620
>20 dB @1620~1625
3 Reflect Band IL >21 dB @1644.5~1655.5
ORL ≤1.0 dB @1644.5~1655.5
4 PDL ≤0.4 dB @1260~1600
5 Ripple ≤0.6 dB @1644.5~1655.5
6 TDL ≤0.5 dB @1260~1600
7 Max Power Optical Handling 27 dBm -
8 Plug Time >500 Times -
9 Connector Mode LC/APC - -



Work & Storage Conditions



Parameter Specification Unit
Working Temp. -25 ~ +65
Working Humidity 5 ~ 95 %RH
Storage Temp. -40 ~ +85
Working Humidity 5 ~ 95 %RH



Single Mode Fiber Optic FBG Reflector / Fiber Optic Reflector Fiber Bragg Grating 0



Hangalaxy FBG Optical Reflector Workshop



Single Mode Fiber Optic FBG Reflector / Fiber Optic Reflector Fiber Bragg Grating 1



Single Mode Fiber Optic FBG Reflector / Fiber Optic Reflector Fiber Bragg Grating 2



Application


1. Detection and maintenance of Passive Optical Network lines (applied to FTTx).



OEM/ODM Service


If you want to display your own brand LOGO on the goods such as cable, package bag, label or any where. It is no any problem. Our OEM and ODM service is always ready to do it.



Packing


(1) According to Stardard Export Packing;
(2) Carton box, wooden box, wooden pallet.



Shipping


(1) International express such as UPS, TNT, DHL, etc;
(2) Internatioal air: CA, AA, EA, etc;
(3) By sea.
