Place of Origin: | China |
---|---|
Brand Name: | Hangalaxy |
Certification: | CE, FDA, SGS, RoHs, ISO9001:2008 |
Model Number: | 001 |
Minimum Order Quantity: | MOQ Saying is 10pcs |
Price: | Negotiation By email or Phone Call |
Packaging Details: | 1PCS Each Individual Quality PE Bag |
Delivery Time: | 7-10 Business Days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 25000PCS Monthly |
Connector 1: | LC UPC | Connector 2: | SC APC |
---|---|---|---|
Fiber Mode: | SM G.652D | Fiber Count: | 12 |
Polish Type: | APC, UPC | Cable OD: | 3.0mm |
Cable Color: | Yellow | Cable Length: | 10m |
High Light: | SM G.652D Pre Terminated Fibre Cable,10m Pre Terminated Fibre Cable,LC APC To LC UPC Optic Cable |
12 Fibers LC APC to LC UPC SM G.652D Singemode Pre Terminated Fiber Optic Cable
Feature & Keyed Characteristic
● Strong, flexible and easy to install;
● Ideal for indoor applications, thanks to the LSZH sheath;
● Great mechanic resistance;
● Totally dielectric.
● Application
√ Data centers.
√ Structured cabling systems.
√ LAN interbuilding installations (Campus) 1, 10, 40 and 100 Gbps applications.
√ Security and transport systems.
√ Community access television (CATV) & multi-system operator (MSO).
√ Central office and local loop.
Item Description
The Hangalaxy Multifiber cable made by 900μm diameter optical patch cords helically wrapped on a central element. It is possible to order the cable with all available connectors.
Technical Parameter
CABLE | YELLOW FANOUT SINGLE-MODE | ||
Applicable standards |
CEI/EN 60793 CEI/EN 60794-1 |
||
CONSTRUCTION PERFORMANCE | |||
Pulling load resistance (N) | 4-6 fo: 600 / 800 | 8 – 12 – 16 fo: 1.000 / 1.500 / 2000 | 18 - 48 fo: 2.000 / 2.500 |
Crush resistance (N/cm) | Da 200 a 250 | ||
Static bending radius (mm) | 10 times x outer diameter | ||
Dynamic bending radius (mm) | 20 times x outer diameter | ||
Temperature (°C) | -20 / +80 | ||
Installing temperature (°C) | -10 / +60 | ||
Temperature (°C) | -20 / +80 | ||
MATERIALS | |||
Outer sheath | LSZH (yellow RAL 1018) | ||
External sheath of single fiber | LSZH (yellow RAL 1018) | ||
Secondary sheath of single fiber | Nylon - SEMITIGHT | ||
Strenght member | Aramid yarns | ||
FIBER | |||
SM - 9/125 | SMF-28e | ||
CONSTRUCTION FEATURES | |||
Number of fibers | 12 | 24 | 48 |
Outer diameter (mm) | 10.5mm | 13.5mm | 17.8 |
Weight (kg/km) | 50 | 78 | 135 |
Single fiber external diameter (mm) | 0.9 ±0,1 | ||
Connectors | Standard of LC, ST, FC, SC etc. |
Application in the field
Fiber Optic Patch Cord, Multi-fiber, Singlemode, 4 fibers, SC/UPC to SC/UPC, yellow, 16 m
