Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3

  • Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
  • Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
  • Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
  • Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3
Place of Origin China
Brand Name Hanglaxy
Certification SGS, CE, RohS, UL, FDA
Model Number HGYN-0147
Minimum Order Quantity MOQ Saying is 10pcs
Price Negotiation By email or Phone Call
Packaging Details 1PCS Each Individual Quality PE Bag
Delivery Time 7-10 Business Days
Payment Terms D/A, D/P, T/T, Western Union, MoneyGram, L/C
Supply Ability 5055PCS Monthly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Material Metal Color White
Fiber Count 24 Connector Type LC UPC
Fiber Mode Multimode, OM3 Dimension 1U, 19inch
Insertion Loss 0.5dB Return Loss 35dB
High Light

fiber optic distribution box

,

ftth termination box
Leave a Message
Product Description

1U 12F Duplex LC UPC Multimode OM3 Fiber Optic Termination Metal Box



Hangalaxy this kind of rack mounted fiber optic patch panel has been designed to facilitate internal fiber management. It is made of 16 gauge steel sheet by electrostatic plastic spraying and providing good protection, connection, termination and management for fibers. The standard 19 inch drawing out design allows fiber installation and maintenance operation from the front. The pigtails color code are according to TIA/EIA 598A , pigtail and adapter are Telcodia, TIA/IEC and JIS compliant. Various pigtail and adapter including ST, FC, SC, LC ect for optional.



Physical Features



Capacity of 24 optical fiber couplers

Front and back protection

Fittings and accessories are mounted

Fiber organizer and fiber identification are included

Weight: 4.8kg at 48x35x4.5cm



Application



Telecommunications
Local Area Network
FTTH deployments
Data Processing Networks



Usage Environment



Environment temperature: -40°~+80°
Relative humidity: ≤85% (30°)
Insulated Resistance:≥2×10MΩ/500V(DC)
Atmosphere pressure: 70~106KPa



Specification



Part Number HGYN-0147
Fiber Capacity 24 fibers
Material Metal
Color White
Connector Type LC UPC
Fiber Mode Multimode, OM3
Dimension 48x35x4.5cm
Weight 1.56kg
Durability 1000times
Relative Humidity ≤85% (30°C)



Usage Environment



Environment Temperature

-40°C~+80°C
Relative Humidity ≤85% (30°C)
Insulated Resistance ≥2×10MΩ/500V(DC)



Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3 0



Product Photo and Accessories



Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3 1



Metal Fiber Optic Distribution Box 1U 12F Duplex LC UPC Multimode OM3 2



Shipment by DHL, UPS, FedEx, TNT
