| Place of Origin: | China |
|---|---|
| Brand Name: | Hangalaxy |
| Certification: | CE, SGS, UL, ROHS |
| Model Number: | HGYN-5588 |
| Minimum Order Quantity: | MOQ Saying is 10pcs |
| Price: | Negotiation By email or Phone Call |
| Packaging Details: | 1PCS Each Individual Quality PE Bag |
| Delivery Time: | 7-10 Business Days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 25000PCS Monthly |
| Connector Type: | FDDI | Polish Type: | UPC |
|---|---|---|---|
| Fiber Mode: | Multimode | Color: | Beige |
| Fiber Count: | 2 | Cable OD: | 3.0mm |
| High Light: | lc apc fiber connector,fc apc fiber connector |
||
2.0mm Fiber Optic MTRJ Singlemode Duplex Field Assembly Connector
Description
Hangalaxy’s distribution box terminates outside optical cables with up to 12 fibers; it allocates 12 adapters for connecting with max 12 drop cable pigtails, it is also suitable for using with mini splitters. The box works under both indoor and outdoor environments. It is a perfect cost-effective solution-provider in the FTTH networks.
Keyed Characteristics
√ ABS material used ensures the body strong and light;
√ Protection Level: IP55;
√ Water-proof design for outdoor uses, lock provided for extra security;
√ Easy installations: Ready for wall mount – installation kit provided;
√ Adjustable adapter slotused – to suit different size pigtails;
√ Space saving! Double-layer design for easier installation and maintenance;
√ Lower layer for splicing, also suitable for mini splitters;
√ Upper layer for adapters, connectors and fiber distribution;
√ Cable fixing units provided for fixing the outdoor optical cable;
√ Both cable glands and tie-wraps accessible;
√ Pre-connectorized cables supported (pre-connected with fast-connectors);
√ Bend radius protected and cable routing paths provided.
Technical Parameter
| Category | Specification | |
| Applicable for | Ф2.0x3.0mm Indoor Flat Cable | |
| Fiber mode | 9/125μm Single-mode | |
| Polish Type | APC / UPC | |
| Dimension | 55mm | |
| Housing | Green / Blue PC Plastic | |
| Ferrule Material | Ceramic (Zirconia) | |
| Operation time | S | About 50(no fiber cut) |
| Insertion Loss | dB | ≤ 0.50 |
| Insertion Loss Typical value | dB | ≤ 0.30 |
| Return Loss | dB | ≥ 45.0 |
| Fastening strength of naked fiber | N | ≥ 5 |
| Tensile strength | N | ≥ 50 |
| Reusable | Time | ≥ 10 times |
| Operating Temperature | ℃ | -40～+75 |
| On-line tensile strength (10N) | dB | ΔIL≤ 0.3 |
| Mechanical durability (500 times) | dB | ΔIL≤ 0.3 |
|
Drop-off test (drop-off height4m,once per direction,totally 3 times) |
dB | ΔIL≤ 0.3 |
| Conformance | TIA/EIA 604-3 | |
Features & Benefits
1. Versatile connector system with a RJ-45 form factor
2. Duplex ferrule
3. Increases port density required on computer and networking related hardware, panels, wall plates, and in closets by 50%
4. Meets TIA-568A standards
5. Low insertion loss:
<.22 dB TYP MM
<.19 dB TYP SM
Applications
(1) Premise infrastructure;
(2) Backbone;
(3) Horizontal;
(4) Local Area Networks (LAN's);
(5) Device terminations;
(6) Telecommunication networks.
