OFNP 40G QSFP+ Active Optical Cable 10m High Speed Cisco Compatible

  • OFNP 40G QSFP+ Active Optical Cable 10m High Speed Cisco Compatible
  • OFNP 40G QSFP+ Active Optical Cable 10m High Speed Cisco Compatible
  • OFNP 40G QSFP+ Active Optical Cable 10m High Speed Cisco Compatible
  • OFNP 40G QSFP+ Active Optical Cable 10m High Speed Cisco Compatible
Place of Origin China
Brand Name Hangalaxy
Certification ROHS, UL, SGS, CE
Model Number HGYN-0984
Minimum Order Quantity MOQ Saying is 10pcs
Price Negotiation By email or Phone Call
Packaging Details 1PCS Each Individual Quality PE Bag
Delivery Time 7 Business Days
Payment Terms L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability 25055PCS Monthly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Manufacturer Hangalaxy Connector Type QSFP+ To QSFP+
Data Rate 40Gbps Minimum Bend Radius 7.5mm
Cable Length 10m Jacket Material OFNP
Protocols 40G InfiniBand 8x DDR, 4x QDR, 10G/40Gigabit Ethernet, Fibre Channel Temperature 0 To 70°C (32 To 158°F)
High Light

40g breakout cable

,

fan out cable
Leave a Message
Product Description

10m High Speed Cisco Compatible 40G QSFP+ Active Optical Cable, OFNP Cable



Active Optical Cable (AOC) is a cabling technology that accepts same electrical inputs as a traditional copper cable, but uses optical fiber “between the connectors”. AOC uses electrical-to-optical conversion on the cable ends to improve speed and distance performance of the cable without sacrificing compatibility with standard electrical interfaces. Hangalaxy SFP28 Active Optical Cable (AOC) is a 25Gbps solution to25G Ethernet, and datacenter. The integrated cable transmits 25Gbps data in each direction over MMF with distance up to 100m. The AOC is SFP+ MSA compliance, low power consumption and lightweight.



Keyed Characteristics


● Electrical interface compliant to SFF-8431;
● 850nm VCSEL laser and PIN photo-detector;
● Maximum link length of 70m on OM3 MMF and 100m on OM4 MMF;
● Digital diagnostics functions are available via the I2C interface;
● 850nm VCSEL laser and PIN photo-detector;
● Holder with guiding (air-/water-cooled);
● Internal CDR on both Transmitter and Receiver channel;
● Single 3.3V power supply;
● Power dissipation < 1W;
● Digital diagnostics functions are available via the I2C interface;
● RoHS-6 compliant;
● Commercial case temperature range: 0°C to 70°C.



Applications


● 25GBASE-SR Ethernet;
● InfiniBand QDR, SDR, DDR;
● Servers, switches, storage and host card adapters.



Absolute Maximum Ratings



Parameter Symbol Min Max Unit
Storage Temperature TST -20 85 ℃
Relative Humidity RH 0 85 ％
Case Operating Temperature TOPC 0 70 ℃
Supply Voltage VCC -0.3 3.6 V



Recommended Operating Conditions



Parameter Symbol Min Typical Max Unit
Operating Case temperature TA 0   +70 ℃
Supply Voltage VCC 3.13 3.3 3.47 V
Supply current Icc     300 mA
Channel Data Rate Dr - 25.78125   Gbps



Transmitter



Parameter Symbol Min Typical Max Unit
Input differential impedance Zin 90 100 110 Ω
Differential Data Input Swing Vin PP 300   1100 mV
Transmit Enable Voltage VEN     0.8 V
Transmit Disable Voltage VD 2.0     V
Average launch power PAVG -7.5 -1 +2.5 dBm
Extinction Ratio ER 2.0     dB
Centre Wavelength λc 840 850 860 nm



OFNP 40G QSFP+ Active Optical Cable 10m High Speed Cisco Compatible 0



CWDM/DWDM Module Facilicy



OFNP 40G QSFP+ Active Optical Cable 10m High Speed Cisco Compatible 1



Hangalxy AWG Module Factory



OFNP 40G QSFP+ Active Optical Cable 10m High Speed Cisco Compatible 2



The rate of Hangalaxy 40G AOC cable is quite stable on our Cisco Nexus 9000 series equipment with no compatibility issue. Very pleased with my first order for nice products' performance. Regarding to my next project, will order FS products again.
