OD 2.0mm FC To Sc Pigtail Multimode Duplex OM2 0.35dB Insertion Loss

Basic Information
Place of Origin: China
Brand Name: Hangalaxy
Certification: CE, SGS, UL, ROHS
Model Number: HGYN-0175
Minimum Order Quantity: MOQ Saying is 10pcs
Price: Negotiation By email or Phone Call
Packaging Details: 1PCS Each Individual Quality PE Bag
Delivery Time: 7-10 Business Days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 25000PCS Monthly
Fiber Type: Multimode, OM2 Fiber Count: 2
Connector 1: FC Connector 2: SC
Cable OD: 2.0mm Cable Color: Orange
Insertion Loss: 0.35dB Return Loss: 45dB
High Light:

patch cord pigtail

,

pigtail fiber optic cable

2.0mm FC to SC Fiber Optic Duplex Multimode OM2 Pigtails Patch Cord



We as a factory can offer a wide range of patch cords, designed and manufactured for demanding network applications. It comprises of multimode and singlemode. Both ends are terminated with a high performance hybrid or single type connector comprising of a SC, ST, FC, LC, MU, MTRJ, E2000, DIN connector in simplex and duplex.



Feature



(1) 100% tested on optical performance (Insertion Loss Customer specified length & Return Loss);

(2) Standard colour is Yellow, Orange, Aqua or Purple, other colours available upon request;

(3) Cable outer jacket available in PVC, Low Smoke Zero Halogen (LSZH);

(4) PC, UPC, APC connectors type available;

(5) High concentricity 2.5mm ceramic ferrule for FC, ST, SC and 1.25mm ceramic ferrule for LC and MU;

(6) Available in G652D, G657A, OM1, OM2, OM3 and OM4;

(7) Position A/Position B markings;

(8) Available in 0.9mm, 1.6mm, 2.0mm, 3.0mm sizes.



Specification



Simplex communications are sent in one direction. As an example, a signal is transmitted via a Simplex Fiber Optic Cable from device A to device B, the signal cannot return from device B via the same cable. Simplex communications include typical residential internet, were a single line is used for downloading data while another is used for uploading data. Devices that are connected via Duplex are able to send data in both directions simultaneously. A good example of a duplex connection is your everyday telephone line, which allows for communications from both parties at the same time.



Material Specification
Singlemode Multimode
Connector Engineering Thermoplastic UL-94 VO
Boot Thermoplastic Elastomer
Fiber 9um Single-mode 50um or 62.5um, Multimode



Test Test Condition / Requirements
Singlemode Multimode
Attenuation ≤0.75dB <0.75dB
Reflection ≤-26dB >20dB
Mating Durability 500 Cycles, <0.75dB Max
Strength of coupling 33N , ≤0.75dB
Plug cable retention

Tensile load 66N, side pull 19.4N,

≤0.75dB

Tensile load 66N, side pull 6.6N, <0.75dB
Plug flex 100 Cycles, ±90 degrees, 0.5kg, <0.75dB
Plug twist 10 Cycles, ±2.5 revolution, 15N, <0.75dB
Cold -10℃ (14°F) for 96 hours, <0.3dB increase
Heat 60℃ (140°F) for 14 days, <0.3dB increase
Humidity 40℃, 95% relative humidity for 96 hours, ≤0.4dB
Impact 8 drops @1.8m, <0.75dB
Thermal Cycling -10℃ to 60℃ (14° to 140°F), 5 cycles, 0.3dB increase
Vibration -10 to 55 Hz, 30min. each axis, <0.3dB increase



  Loss (dB) Reflection (dB)
1310 850 1310 850
Mean 0.28 0.37 -33.3 -32.7
Sigmal 0.17 0.17 1.83 1.57



OD 2.0mm FC To Sc Pigtail Multimode Duplex OM2 0.35dB Insertion Loss 0



OD 2.0mm FC To Sc Pigtail Multimode Duplex OM2 0.35dB Insertion Loss 1



OD 2.0mm FC To Sc Pigtail Multimode Duplex OM2 0.35dB Insertion Loss 2



As a result of this the number of reflections resulting from the light traveling down the core are dramatically reduced. This in turn lowers the attenuation and allows the signal to travel both faster and further. If it helps, think of it in terms of water flowing through a very thin hose pipe, it will be more compressed, travel faster and further through small the hose than through a large one.



50um Loss & Reflection Typical Performance



  Loss (dB) Reflection (dB)
1.310 1.310
Mean 0.20 -56.2
Signal 0.18 3.4



Quality Guarantee



Hangalaxy has those fiber optical patch cables in stock and ready to ship. This cable is tested for 100% functionality and guaranteed compatible for outstanding network performance. Now you have a reliable, compatible and affordable means to expand your network while maintaining its integrity. We can provide this cable in any lengths. If the length you need is not listed on our website, please feel free to contact us.
