Multimode OM3 Fiber Optic MPO MTP Cable Yellow Flat LSZH Broadband
Place of Origin | China |
---|---|
Brand Name | Hangalaxy |
Certification | CE, UL, ROHS, SGS |
Model Number | HGYN-01445 |
Minimum Order Quantity | MOQ Saying is 10pcs |
Price | Negotiation By email or Phone Call |
Packaging Details | 1PCS Each Individual Quality PE Bag |
Delivery Time | 7-10 Business Days |
Payment Terms | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability | 25000PCS Monthly |
Contact me for free samples and coupons.
Whatsapp:0086 18588475571
Wechat: 0086 18588475571
Skype: sales10@aixton.com
If you have any concern, we provide 24-hour online help.
xJacket Color | Aqua | Cable OD | 3.0mm |
---|---|---|---|
Fiber Mode | Multimode, OM3 | Material | LSZH |
Connector | MTP | Name | MPO 24 Fiber Cable |
High Light | Multimode Fiber Optic MPO MTP Cable,Yellow Fiber Optic MPO MTP Cable,OM3 broadband Fiber Optic Cable |
Multimode OM3 MPO MTP Fiber Optic Cable Yellow Flat LSZH Broadband
24 Cores Fiber Optic MTP to MTP Multimode OM4 Aqua LSZH Patch Cable
Benefits & Features
* Quick, highly repeatable, low-loss connections
* Simplex & Duples
* Singlemode & Multimode
* PC, UPC & APC polishing
* Various boot (cable) sizes available
* FC/ LC/ SC/ ST/ MTR/ MPO connectors available
* Interferential parameters
* Hybrid patch-cords are available upon request
* Low Insertion loss
* Low PDL
Applications
• Telecommunication Networks
• Data Communication Networks
• Optical System Access Networks
• Broadband / CATV Networks
• Equipment / Switch Interconnections
Technical Information
Parameters | Min | Typical | Max | Unit | |
Operating Wavelength | Single Mode OS1/OS2 | 1310/1550 | nm | ||
Insertion Loss | Single Mode Low Loss | Min 0.3 & max 0.5 | dB | ||
Return Loss | Single Mode | 60 | |||
Fiber Type | SMF-28e G652 and G657 Fiber | ||||
Connector Type | MPO/MTP®, meet standard customized | ||||
Length | 1 meter or meet customized length | Meters | |||
Length Tolerance |
L < 1m | ±50 | mm | ||
1m < L < 3m | ±100 | ||||
3m < L < 10m | ±200 | ||||
L > 10m | ±3 | ||||
Jacket Type | Flat Cable / Round Cable | OFNP / OFNR | |||
Jacket Diameter | 3.0mm, 4.5mm, 5.0mm or meet customized | mm | |||
Jacket Color | Yellow | SMF-28e G652 and G657 Fiber |
Environmental Condition
Parameters | Unit | Specification | |
Min | Max | ||
Uncontrolled Environment | ℃ | -40 | +75 |
Controlled Environment | ℃ | -10 | +60 |
Packing Information
1PCS Each Individual Quality PE Bag
Ordering Information
Lower Insertion Loss & Higher Performance | ||
8 fibers used when mated with 40G QSFP+ transceivers. | 0.35dB Low IL and stable signal transmission ensuring your network safety. | High-quality MTP connectors tested and guaranteed by 3D interferomete. |
