LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua

  • LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua
Place of Origin China
Brand Name Hangalaxy
Certification CE, FDA, SGS, RoHs, ISO9001:2008
Model Number HGYN-001
Minimum Order Quantity MOQ Saying is 10pcs
Price Negotiation By email or Phone Call
Packaging Details 1PCS Each Individual Quality PE Bag
Delivery Time 7-10 Business Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 25000PCS Monthly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Fiber Count 12 Cores Cable OD 3.0mm
Connector Type MTP, USConec Length 10feet
Glass Fiber Corning ClearCurve® Wavelength 850nm/1300nm
High Light

12 Cores Fiber Optic MPO Cable

,

LSZH MTP Fiber Optic MPO Cable

,

OM3 Aqua MPO MTP Cable
Leave a Message
Product Description

10 FT Fiber Cable LSZH MTP OFNR 12 Cores Multimode OM3 Aqua



12 Cores Fiber Optic Multimode MTP to MTP Female End Aqua OM3 Trunk Cable



Products Description



Hangalaxy's MTP trunk cable, a cost-effective alternative to time-consuming field termination, is designed for high-density fiber patching in data centers which need space saving and reduce cable management troubles. With US Conec MTP connectors and Corning Clearcurve fiber, it is optimized for 10/40/100G high-density data center applications. Please note: The US Conec MTP connectors are fully compliant with the MPO standards, achieving higher performance levels when compared to generic MPO connectors. And today we has 12F and 24F MTP Cable for producing and our quality to meet your standard requested.



Keyed Characteristics


• NTT Compatible;
• Low loss interconnect;
• Push-pull mating of MTP for quick connections;
• 100% tested;
• Compliance with the 40 and 100Gbps protocols.
• Consistent and repeatable performance.



Cable Performance





Fiber Type (ISO/IEC 11801) 50/125um, OM3, Aqua

Attenuation Coefficient (dB/km)

 ≤ 3.5 Max (850nm)
≤ 1.5 Max (1300nm)
≤ 2.7 Typ (850nm)
≤ 0.9 typ (1300nm)

Standards Compliance

 TIA/EIA-568-C.3 and ISO/IEC 11801
Color Options MM Elite (Aqua)
Minimum Bandwidth: Laser Effective Modal Bandwidth[Mhz-km] ≥2000 (850nm)
Jacket Material Riser - OFNR
LSZH - Low Smoke Zero Halogen
Plenum - OFNP
Plenum - OFNP



Connector Performance - MTP®



Type and Color Code Connectors Insertion Loss (IL) Optical Return Loss (RL) Operating Temperature
Multimode MTP® Standard Connector 0.35 dB Typical (All Fibers)
0.75 dB Maximum (Single Fiber)1,3		 > 20 dB (0°Flat Polished)2,3 -40℃ to 75℃
1 IL test according to IEC 61300-3-4;
2 RL test according to IEC 61300-3-6;
3 Tested with proposed encircled flux launch condition on 50μm fiber & 850nm per IEC 61280-4-1.







Application

  • Telecommunication networks
  • Data centers
  • Supports SFP, QSFP, CFP applications
  • 40G to 10G transition
  • CATV;
  • Active device termination;
  • Telecommunication networks;
  • Metro;
  • Local Area Networks;
  • Data processing networks
  • Test equipment;
  • Premise installation;
  • Wide Area Networks



Testing Equipment





LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua 0



Products Picture



LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua 1



LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua 2



LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua 3



Eco-Friendly Packaging & Labeling


This easy to take and well-protected fiber optical cable package has been labeled and marked by Hangalaxy as default. Customized label or package solution are available on request.



LSZH MTP OFNR 10 Foot Optical Cable 12 Cores Multimode OM3 Aqua 4
