2.0mm Single mode Fiber Optic Patch Cables LC UPC / Fiber Optic Jumper

Place of Origin China
Brand Name Hanagalaxy
Certification CE, SGS, FDA, UL
Model Number HGYN-0616
Minimum Order Quantity MOQ Saying is 10pcs
Price Negotiation By email or Phone Call
Packaging Details 1PCS Each Individual Quality PE Bag
Delivery Time 7-10 Business Days
Payment Terms L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability 20000PCS Monthly

Contact me for free samples and coupons.

Whatsapp:0086 18588475571

Wechat: 0086 18588475571

Skype: sales10@aixton.com

If you have any concern, we provide 24-hour online help.

x
Product Details
Color Yellow Cable OD 2.0mm
Cable Jacket PVC Connector 1 LC APC
Connector 2 LC APC Fiber Count 2F
Insertion Loss 0.35dB Return Loss 45dB
High Light

optical fiber jumper

,

fiber optic jumper cables

Leave a Message
Product Description

2.0mm Fiber Singlemode OS2 Optic LC UPC Duplex Patch Cables OFNP Yellow Jacket



The 9/125μm OS2 single mode bend insensitive fiber optic cable is less attenuation when bent or twisted compared with traditional optical fiber cables and this will make the installation and maintenance of the fiber optic cables more efficient. It can also save more space for your high density cabling in data centers, enterprise networks, telecom room, server farms, cloud storage networks, and any places fiber patch cables are needed. This 9/125 OS2 single mode fiber optic cable is ideal for connecting 1G/10G/40G/100G/400G Ethernet connections. It can transport data for up to 10km at 1310nm, or up to 40km at 1550nm.


Product Spotlights



1. Bend Insensitive Fiber


(1) YOFC G.657.A1 bend insensitive fiber;

(2) 10.0mm minimum bend radius;



2. Certification & Standards


(1) ISO 9001;

(2) RoHS, REACH compliant;

(3) IEC 61754, TIA 604 (FOCIS), YD/T;



3. Test Assured Program


(1) Insertion loss and return loss testing;

(2) End-face inspection;

(3) 3D interferometer test;


Feature



1. Low insertion loss and back reflection loss;
2. Good Durability;
3. Good exchangeability;
4. High temperature stability;
5. Standard: Telcordia GR-326-CORE;

6. Compact design;

7. IEC,JIS,TELCORDIA-326 compliance.



Product Classification



Connector Polish Type Optical Properties Reference Standard
SM MM
IL (dB) RL (dB) IL (dB) RL (dB) YD/T 1272.3-2005;IEC 60874-19-1 IEC 60874-14-5;IEC 60874-14-10
SC UPC ≤0.35 ≥50 ≤0.20 -
APC ≥60 - -
Operating Temperature(℃) -40℃~+80℃
Storage Temperature(℃) -40℃~+85℃
Fireproof standard IEC 60332-3
RoHs 2002/95/EC directive



Regional Availability China
Product Type Fiber pigtail, multi-fiber
Color, boot A White
Color, connector A White
Jacket Color White
Fiber Count 1
Nominal Diameter (mm) 5.0
Fiber Mode Singlemode
Fiber Type OS1
ROHS Compliant/Exempted


Cable Parameter


Category

Description

Specifications

Before cabling

After cabling

Attenuation @1550 nm

≤0.20 dB/km (max.) ≤0.22 dB/km (max.)

Attenuation @1625 nm

≤0.23dB/km ≤ 0.24 dB/km

Zero Dispersion Wavelength

≤1520 nm

Zero Dispersion Slope

≤ 0.084 ps/nm2·km

PMD Link value (M=20cables Q=0.01% )

maximum PMDQ

≤0.08 ps/√km

Cable Cutoff Wavelength (λcc)

≤1450 nm

Macro bending Loss

(1 turn; Ф32 mm) @1550 nm

(100 turns; Ф60 mm) @1625 nm
(100 turns; Ф50 mm) @1310 &@1625 nm

≤ 0.05 dB
≤ 0.05 dB
≤0.05 dB

Mode Field Diameter

@1550 nm 9.6±0.5μm

Dimensional Specifications

Cladding Diameter

124.8 ±0.7μm

Core/clad concentricity error

≤0.6μm

Cladding Non-Circularity

≤1.0%



Proof stress off line

≥9.0 N
≥1.0 %
≥100 kpsi



2.0mm Single mode Fiber Optic Patch Cables LC UPC / Fiber Optic Jumper 0

2.0mm Single mode Fiber Optic Patch Cables LC UPC / Fiber Optic Jumper 1


Hangalaxy Exhibition Activities


2.0mm Single mode Fiber Optic Patch Cables LC UPC / Fiber Optic Jumper 2


Quality Control


Quality and standards are the foundation of Hangalaxy. We are dedicated to providing clients with the outstanding, standards-compliant products and services. Hanglaxy has passed many quality system verification, like ISO, RoHS, established an internationally standardized quality assurance system and strictly implemented standardized management and control in the course of design, development, production, installation and service.
