| Place of Origin: | China |
|---|---|
| Brand Name: | Hangalaxy |
| Certification: | CE, SGS, UL, RoHs |
| Model Number: | HGYN-0150 |
| Minimum Order Quantity: | MOQ Saying is 10pcs |
| Price: | Negotiation By email or Phone Call |
| Packaging Details: | 1PCS Each Individual Quality PE Bag |
| Delivery Time: | 7-10 Business Days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 20000PCS Monthly |
| Cable OD: | 0.9mm | Jacket: | PVC |
|---|---|---|---|
| Cable Color: | Color-coded | Connector: | MTRJ |
| Polish Type: | UPC | Fiber Count: | 12 |
| Fiber Mode: | Multimode | Wavelength: | 850nm |
| High Light: | fiber optic pigtail splicing,pigtail fiber optic cable |
||
15 Meters Fiber Optic MTRJ Multimode OM3 Ribbon Fanouit Kits PVC Pigtails
Product Features
(1) 100% Optically Inspected and Tested for Insertion Loss;
(2) Pull Proof Jacket;
(3) Immune to Electrical Interference;
(4) ROHS Compliant.
Features
1. Standard length of three meters. Custom lengths available upon request;
2. All connectors have precision pre-radiused zirconia ferrules;
3. Corning glass fiber or equivalent;
4. Other connectors available upon request (MU, FC, MT-RJ);
5. 0.9 mm tight buffered OFNR cable (white) in 62.5/125 μm, 50/125 μm, 50/125 μm (10G, 300 m) laser optimized, and single-mode.
Application
1. Local area networks (LAN);
2. Wide area networks (WAN);
3. CATV, metro test equipment;
4.Telecommunication networks;
5. Data processing networks;
6. Premise installations;
7. Video and military active device termination.
Technical Parameter
| Fiber Type | SM | MM | |||
|
Connector Tytpe |
MTRJ |
D4, FC, SC, ST, LC, E-2000, MU |
D4, FC, SC, ST, LC, E-2000, MU |
MTRJ | |
| Insertion Loss (Typical) | ≤0.4dB | ≤0.2dB | ≤0.4dB | ≤0.2dB | |
| Insertion Loss (Max) | ≤0.5dB | ≤0. 3dB | ≤0.3dB | ≤0.5dB | |
|
Return Loss (Typical) |
PC | ≥50dB | |||
| APC | ≥65dB | ||||
| UPC | ≥55dB | ≥55dB | |||
| Mating Durability | ≤0.2dB | ||||
| Durability | ≥1000 times | ||||
| Storage Temperature | - 40～+ 85 | ||||
| OVERVIEW | |
| Clad Diameter | 125 Micron |
| Core Diameter | 62.5 Micron |
| No. Of Fiber | 2 |
| Technology | Mode Conditioning |
| Push/Pull Tabs | No |
| Weight (Lbs) | 0.09 |
| WARRANTY | |
| Product Warranty Period (Worldwide) | Lifetime limited warranty |
| Legend / Key | |||||||
| Connectors | Fiber Modes | Fiber Count | Jacket Color | Jacket Type | UOM (Unit of Measure) | Cable Diam Ø | |
|
D: SC/UPC E: SC/APC F: E2000 G: E2000/APC H: FC/UPC I: FC/APC K: LC/UPC L: LC/APC S: ST/UPC Y: MT-RJ |
9: 9/125μm Single-mode 6: 6.25/125μm Multimode 7: 50/125μm OM3 Laser Optimized Multimode 4: 50/125μm OM4 2: 200/230μm Multimode 1: 100/140μm Multimode P: Panda PM Fiber B: Bowtie PM Fiber E: Eliptical PM Fiber |
S: Simplex (1 Fiber) D: Duplex (2 Fiber) |
Y: Yellow O: Orange A: Aqua L: Blue G: Green E: Brown S: Slate W: White R: Red B: Black U: Purple P: Pink |
R: Riser (OFNR) P: Plenum (OFNP) L: Low Smoke Zero Halogen (LSZH) N: None V: PVC Jacket |
M: Meters F: Feet I: Inches C: Centimeters |
2: 2mm Jacket 3: 3mm Jacket 4: 900μm (.9mm) 6: 250μm Bare 7: 500μm Bare |
|
Quality Control
Quality and standards are the foundation of Hangalaxy. We are dedicated to providing clients with the outstanding, standards-compliant products and services. Hanglaxy has passed many quality system verification, like ISO, RoHS, established an internationally standardized quality assurance system and strictly implemented standardized management and control in the course of design, development, production, installation and service.
Shipping Return
Ribbon fan-out pigtails generally have two types:jacket ribbon fan-out pigtails and bare ribbon fan-out pigtails. Jacket ribbon fan-out pigtails have outer jacket on fiber ribbon. Bare ribbon fan-out pigtails have no outer jacket and generally protected by transparent tube.
