|Place of Origin:||China|
|Certification:||CE, UL, SGS, ROHS, ISO9001|
|Minimum Order Quantity:||MOQ Saying is 10pcs|
|Price:||Negotiation By email or Phone Call|
|Packaging Details:||1PCS Each Individual Quality PE Bag|
|Delivery Time:||7 Business Days|
|Payment Terms:||L/C, D/A, D/P, T/T, Western Union, MoneyGram|
|Supply Ability:||15000PCS Monthly|
|Attenuator Values:||5dB||Attenuator Tolerance:||<5 DB: +0.4|
|Fiber Mode:||Singlemode||Connector Type:||LC UPC|
single mode fiber attenuator,
variable optical attenuator
1550nm 15dB LC UPC Fixed Singlemode Fiber Optic Hybrid Attenuators
2. CATV & LAN systems;
3. Test and data equipment;
4. Passive Optical Networks;
5. Test Areas/Labs.
1. Very cost-effective;
2. Excellent stability and repeatability;
3. Environmentally stable;
4. Polarization insensitive.
|Attenuation values||0~10 dB / 15dB / 20dB / 25dB /Specified|
|Connector Type||FC, SC, ST, LC, MU, E2000, MPO||FC, SC, E2000, LC, MPO|
|Attenuation Accuracy||<±0.45dB for 0-10dB , <±1dB for 11-30dB|
|Wave Length||850nm, 1310nm 1550nm, 1310nm & 1550nm|
|Operating Temperature||-40℃ ~ +80℃|
|Storage Temperature||-55℃ ~ +85℃|
Ordering Information - Optical Attenuator
|Fiber Type||Connector Type||Polish Type||Attenuation||Operating Wavelength|
5-50/125 6-62.5/125 9-9/125
Other Hangalaxy Products
Passive Optical Components, Fixed/Variable Attenuators, Fiber Patch Cords and Pigtails, Couplers and Splitters.
Hangalaxy Exhibition Activities
Optical attenuators are typically classified as fixed or variable attenuators. Fixed attenuators have a fixed optical power reduction number, such as 1dB, 5dB, 10dB, etc. Variable attenuators’ attenuation level can be adjusted, such as from 0.5 dB to 20dB, or even 50dB. Some variable attenuators have very fine resolution, such as 0.1dB, or even 0.01dB.
Hangalaxy has those fiber optical attenuators in stock and ready to ship. This cable is tested for 100% functionality and guaranteed compatible for outstanding network performance. Now you have a reliable, compatible and affordable means to expand your network while maintaining its integrity. We can provide this cable in any lengths. If the length you need is not listed on our website, please feel free to contact us.
Questions & Answers
Q: Is there any difference in application between the single mode and multimode optical attenuator?
A: There is no difference in application between the single mode and multimode optical attenuators. The separate colours are designed for matching colours of fiber patch cables, proving convenience for distinguishing corresponding cables when cabling.
Q: Hi! What's the Ø of the fixing hole?
A: The diameter of the fixing hole hole is 2.0mm, and please kindly note that the M2*8 screw could be used for mounting.
